Name: 2026 Trek Madone SL 6 Gen 8
Brand: Trek
SKU: 4576656
Availability: InStock

Description

A carbon frame aero bike with upper mid-range components and hydraulic disc brakes.

Build

Frame	500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142×12 mm thru axle BB Standard: T47, Threaded Hanger Standard: UDH Tire Clearance: 32c Colors: Gloss Dark Star / Matte Deep Smoke; Matte Lavender Haze / Deep Smoke; Gloss Fury Red / Matte Deep Smoke; Gloss Crystal White / Matte Deep Smoke
Fork	Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat-mount disc, 12×100 mm chamfered thru axle
Bottom Bracket	Praxis, T47 threaded, internal bearing
Stem	Size: XS, Trek RCS Pro, -7-degree, 80 mm length; Size: S, M, Trek RCS Pro, -7-degree, 90 mm length; Size: ML, L, Trek RCS Pro, -7-degree, 100 mm length; Size: XL, Trek RCS Pro, -7-degree, 110 mm length
Handlebar	Size: XS, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 36 cm control width, 40 cm drop width; Size: S, M, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 38 cm control width, 42 cm drop width; Size: ML, L, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 40 cm control width, 44 cm drop width; Size: XL, Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop, 42 cm control width, 46 cm drop width
Saddle	Bontrager Aeolus Elite, austenite rails, 145 mm width
Seatpost	Madone aero carbon seat post, 0 mm offset, short length Type: Rigid

Groupset

Rear Derailleur	Shimano 105 R7150 Di2, 36T max cog
Front Derailleur	Shimano 105 R7150 Di2, braze-on, down swing
Crank	Size: XS, S, Shimano 105 R7100, 50/34, 165 mm length; Size: M, ML, Shimano 105 R7100, 50/34, 170 mm length; Size: L, XL, Shimano 105 R7100, 50/34, 172.5 mm length
Cassette	Shimano 105 7101, 11-34, 12-speed
Chain	Shimano SLX M7100, 12-speed
Brakes	Hydraulic Disc Type: Hydraulic Disc

Wheels

Rims	Front: Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 100×12 mm thru axle, Rear: Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50 mm rim depth, Shimano 11-speed freehub, 142×12 mm thru axle
Tires	Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700×28 mm

Additional information

Color	Gloss Crystal White, Gloss Dark Star, Gloss Fury Red / Matte Deep Smoke, Matte Lavander Haze
Size	LG, MD, MD/LG, SM, XL, XS
