Description
A 27.5″ aluminum frame full suspension enduro e-bike with upper mid-range components.
| Frame |
Alpha Platinum Aluminum, Removable Integrated Battery (RIB 2.0), tapered head tube, guided internal routing, Motor Armor, angle-adjust headset, Mino Link adjustable geometry, adjustable leverage rate, 34.9mm seat tube, ABP, UDH, Boost148, 12 mm thru axle, 160 mm travel Hanger Standard: UDH Tire Clearance: 2.6″ Colors: Dark Star; Powersurge |
|---|---|
| Fork |
RockShox ZEB Select, DebonAir spring, Charger RC damper, tapered steerer, 44mm offset, Boost110, Maxle Stealth, 160mm travel Travel: 160mm Spring Type: Air |
| Shock |
RockShox Super Deluxe Select RT, 205mm x 65mm Travel: 160mm |
| Headset |
Integrated cartridge bearing, 1-1/8” top, 1.5” bottom, angle adjust cup compatible |
| Stem |
Bontrager Elite, 35mm, 0 degree, 45mm length |
| Handlebar |
Bontrager Line, alloy, 35mm, 27.5mm rise, 780mm width |
| Saddle |
Bontrager Verse P3, steel rails |
| Seatpost |
Size: S, Bontrager Line Dropper, 150mm travel, MaxFlow, internal routing, 34.9mm, 410mm length; Size: M, L, XL, Bontrager Line Dropper, 170mm travel, MaxFlow, internal routing, 34.9mm, 450mm length; Size: L, XL, Bontrager Line Dropper, 200mm travel, MaxFlow, internal routing, 34.9mm, 515mm length Type: Dropper |
| Pedals |
VP-536 nylon platform |
| Grips |
Bontrager XR Trail Comp, nylon lock-on |
| Rear Derailleur |
Shimano XT M8100, long cage |
|---|---|
| Crank |
E*thirteen E*spec Plus, 160mm length |
| Shifters |
Shimano SLX M7100, 12 speed |
| Cassette |
Shimano Deore M6100, 10-51, 12 speed |
| Chain |
Shimano SLX M7100, 12 speed |
| Brakes |
SRAM DB 8 4-piston hydraulic disc Type: SRAM DB8 Hydraulic Disc |
| Rims |
Front: Size: S, Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 27.5”; Size: M, L, XL, Bontrager Line Comp 30, Tubeless Ready, 6-bolt, Boost110, 15mm thru axle, 29”, Rear: Bontrager Line Comp 30, High Strength 6000 Series Aluminum rim, Tubeless Ready, Rapid Drive 108, 6-bolt, Shimano MicroSpline freehub, Boost148, 12mm thru axle, 27.5” |
|---|---|
| Tires |
Size: S, M, L, XL, Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 27.5×2.50”; Size: M, L, XL, Bontrager Brevard Pro XR, Tubeless Ready, dual compound, aramid bead, 60 tpi, 29×2.50” |
| Disc Rotors |
SRAM CenterLine, 6-bolt, round edge, 200mm |
| Motor |
Bosch Performance Line CX, 20 mph / 32 km/h max assist (25 km/h max assist in EU and APAC) |
|---|---|
| Battery |
Bosch PowerTube 800Wh, smart system Recycling Program: |
| Remote |
Bosch System Controller BRC3100, smart system |
| Charger |
Bosch standard 4A, 110V, smart system |
| Fenders |
Trek 27.5″ custom fender |
|---|
